CHD - MOUNTED V TYPE HEAVY DISCHARROW
CHD - MOUNTED V TYPE HEAVY DISCHARROW


Product Equipment
CEMENTED SCRAPERS CEMENTED SCRAPERS

MOUNTED AND TRAILED WORKING MOUNTED AND TRAILED WORKING

ADJUSTMENT TOOL BAR ADJUSTMENT TOOL BAR

LONG LIFE BEARING LONG LIFE BEARING

FURROW CLOSER FURROW CLOSER

HYDRAULIC ANGLE ADJUSTMENT HYDRAULIC ANGLE ADJUSTMENT

Technical Specifications
MODEL
NUMBER OF DISCS
DISC DIMENSION
(mm)
 DISC TO DISC DISTANCE (cm)
NUMBER OF BEARING
(pcs)
FRAME SIZE
(cm)

WEIGHT

(kg)

WORKING WIDHT (cm)

TRANSPORT WIDHT

(cm)

 POWER REQUIREMENT
CHD-16
 16 560x4, /610x5 /660x6 22 4 100x100x6 866 176 215 55-65
CHD-18 18 560x4, /610x5 /660x6 22 4 100x100x6 985 198 237 65-75
CHD-20 20 560x4, /610x5 /660x6 22 6 100x100x6 1106 220 259 75-85
CHD-22 22 560x4, /610x5 /660x6 22 8 100x100x6 1223 242 281 85-95
CHD-24 14 560x4, /610x5 /660x6 22 8 100x100x6 1345 264 303 95-105
CHD-26 26 560x4, /610x5 /660x6 22 8 100x100x8 1565 286 325 105-115
CHD-28 28 560x4, /610x5 /660x6 22 8 100x100x8 1794 308 347 115-125

The specified horsepower may vary by up to ±20% depending on soil conditions and tractor model differences (e.g., 4WD, etc.)

Product Pictures
