TDG-MK SERIES FOLDABLE TRAILED TYPE DISC CULTIVATOR
TDG-MK SERIES FOLDABLE TRAILED TYPE DISC CULTIVATOR

                 Ozdoken TDG-MK series is produced from 450 cm to 600 cm working width and is suitable for tractors between 130-210 horsepower. TDG series, thanks to its independent disc structure, allows serial operation  All TDG series have conical bearing and dust seal, sliding battery as standart.



TRAILED TYPE

300 CM TRANSPORT WIDTH

STANDART CAGE TYPE ROLLER

STANDART 510X4,0 MM DISC DIMENSION

OPTIONAL 560X4,5 MM DISC DIMENSION

Product Equipment
STANDART CAGE ROLLER STANDART CAGE ROLLER

CONICAL BEARING WITH GREASE POINT CONICAL BEARING WITH GREASE POINT

RUBBER DISC SUSPENSION RUBBER DISC SUSPENSION

On TDG series, each disc has individually rubber suspension.

STANDART BATTERY SLIDER STANDART BATTERY SLIDER

Technical Specifications
Model
# of Disc
Disc Dimension
Distance Between Discs
 Working Width (cm) Transport Width (cm) Tyre Size Minimum Weight (kg)
Power Requirement
TDG- MK36 36    510X4,0 / 560X4,5 24,5  450 300 400/60-15.5 3600 130-150 hp  97-112 kW
TDG-MK40 40   510X4,0 / 560X4,5 24,5  500 300 400/60-15.5 3900 150-180 hp 112-135 kW
TDG-MK48 48   510X4,0 / 560X4,5 24,5  600 300 400/60-15.5 4220 180-210 hp 135-157 kW
Product Pictures
OZDOKEN TDG-MK SERIES
watch OZDOKEN TDG-MK SERIES
