BOLT-JOINED frame
Hardox made legs
Patented LEG protection system
thanks To The Patented Center Of Rotation, When The Safety Pin Breaks, The Leg Is Released Without Entering The Ground To Prevent Any Damage To The Leg And Body.
Double 140 MM spike roller
Paralelogram roller connection
Spare PIN
Hyropneumatic protected legs
Hydraulic acumulator
130-330
hp tractor power
225-540
cm working width
Product Equipment
BOLT-JOINED frame
Hardox made legs
Patented LEG protection system
thanks To The Patented Center Of Rotation, When The Safety Pin Breaks, The Leg Is Released Without Entering The Ground To Prevent Any Damage To The Leg And Body.
Double 140 MM spike roller
Paralelogram roller connection
Spare PIN
Hyropneumatic protected legs
Hydraulic acumulator
Technical Specifications
| Model | BOLTAN-PRO560 | BOLTAN-PRO760 | BOLTAN-PRO960 | BOLTAN-PRO545 | BOLTAN-PRO745 | BOLTAN-PRO945 |
|---|---|---|---|---|---|---|
| NUMBER OF LEGS (pcs) | 5 | 7 | 9 | 5 | 7 | 9 |
| WEIGHT (kg) | 1680 | 2044 | 2400 | 1350 | 1625 | 2075 |
| WORKING WIDTH (cm) | 300 | 420 | 540 | 225 | 315 | 405 |
| TRANSPORT WIDTH (cm) | 285 | 405 | 525 | 225 | 300 | 400 |
| POWER REQUIREMENT (hp) | 130-150 | 170-200 | 230-270 | 150-200 | 180-250 | 220-330 |
